Status: Status unknown
A 10-bay short-depth 2U rackmount NAS with 8 front SATA bays, 2 rear NVMe slots and dual redundant power supplies, so it keeps running if one fails. It has an Intel Atom quad-core, 8 GB of DDR5 with ECC, two 2.5GbE ports and a PCIe slot for 10GbE, and runs the ZFS-based QuTS hero or QTS. It launched in early 2025.
| Bays | 8 |
|---|---|
| CPU | Intel Atom x7405C |
| Cores / Threads | 4 / - |
| RAM | 8 GB |
| Product category | - |
| Badge | - |
| Hardware support status | - |
| OS/app support | - |
| Technical support end | - |
| Recommended replacement | - |
| Release year | 2025 |
| RAID levels | JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| PCIe slot types | 1x PCIe Gen 3 x2 |
| RAM (max) | 16 GB |
| Memory generation | DDR5 |
| Memory speed (MT/s) | 5600 MT/s |
| ECC memory | Supported |
| Memory module type | SODIMM |
| Network ports | 2x 2.5GbE |
| USB ports | 1x USB 3.2 Gen 2 + 3x USB 2.0 |
| PCIe expansion | 1 |
| Drive bay types | 3.5" SATA HDD, 3.5" SATA SSD, 2.5" SATA HDD, 2.5" SATA SSD |
| Hot-swappable bays | Yes |
| CPU frequency (GHz) | 3.4 |
| Power supply (W) | 300 |
Documents
Compatible Drives
12 drives certified on TS-h1065eU-RP's official manufacturer compatibility list, sourced directly from QNAP's own published Hardware Compatibility List. Each model links to that drive's own compatibility page.
Certified drives by capacity
Show all 12 certified drives
| Brand | Model | Capacity | Type | Verified drive details | Recently observed offers | Status | Firmware |
|---|---|---|---|---|---|---|---|
| Seagate | ST16000NM001G details | 16 TB | 3.5" Enterprise HDD | 7200 RPM · 256 MB cache · CMR · 550 TB/year workload · 2500000 h MTBF · 5-year warranty | New: $349.00 · Refurb: $424.99 | - | - |
| Western Digital | WD80EFPX details | 8 TB | 3.5" NAS HDD | 5640 RPM · 256 MB cache · CMR · 180 TB/year workload · 1000000 h MTBF · 3-year warranty | New: $299.99 · Used: $637.75 | - | - |
| Western Digital | WD8005FFBX details | 8 TB | 3.5" NAS HDD* | 7200 RPM · 256 MB cache · CMR · 550 TB/year workload · 2000000 h MTBF · 5-year warranty | New: $446.82 | - | - |
| Seagate | ST8000VN004 details | 8 TB | 3.5" NAS HDD | 7200 RPM · 256 MB cache · CMR · 180 TB/year workload · 1000000 h MTBF · 3-year warranty | New: $316.49 | - | - |
| Seagate | ST8000NE001 details | 8 TB | 3.5" NAS HDD | 7200 RPM · 256 MB cache · CMR · 300 TB/year workload · 1200000 h MTBF · 5-year warranty | New: $408.35 · Refurb: $314.99 | - | - |
| Toshiba | HDWG180 details | 8 TB | 3.5" NAS HDD | 7200 RPM · 256 MB cache · CMR · 180 TB/year workload · 1000000 h MTBF · 3-year warranty | New: $576.08 · Used: $189.00 | - | - |
| Western Digital | WD60EFPX details | 6 TB | 3.5" NAS HDD | 5400 RPM · 256 MB cache · CMR · 180 TB/year workload · 1000000 h MTBF · 3-year warranty | New: $315.04 | - | - |
| Western Digital | WD40EFPX details | 4 TB | 3.5" NAS HDD | 5400 RPM · 256 MB cache · CMR · 180 TB/year workload · 1000000 h MTBF · 3-year warranty | New: $133.98 | - | - |
| Western Digital | WD4005FFBX details | 4 TB | 3.5" NAS HDD* | 7200 RPM · 256 MB cache · CMR · 550 TB/year workload · 2000000 h MTBF · 5-year warranty | New: $269.49 | - | - |
| Seagate | ST4000VN006 details | 4 TB | 3.5" NAS HDD | 5400 RPM · 64 MB cache · CMR · 180 TB/year workload · 1000000 h MTBF · 3-year warranty | New: $161.57 · Used: $159.99 | - | - |
| Seagate | ST4000NE001 details | 4 TB | 3.5" NAS HDD | 7200 RPM · 256 MB cache · CMR · 300 TB/year workload · 1200000 h MTBF · 5-year warranty | New: $139.00 · Used: $127.50 | - | - |
| Toshiba | HDWG440 details | 4 TB | 3.5" NAS HDD | 7200 RPM · 256 MB cache · CMR · 180 TB/year workload · 1000000 h MTBF · 3-year warranty | No recent verified offer | - | - |
* Type decoded from the drive model number, not stated by the NAS manufacturer.
Extra drive details are published only from manufacturer-owned documents or explicit human review. Follow the model link for field-level sources.
