Status: Legacy / discontinued
A 2U rackmount enterprise storage server with 30 hot-swap 2.5-inch bays - 24 up front and 6 in the rear for SSD caching. It runs an Intel Xeon D with up to 128 GB of ECC memory, boots either QTS or ZFS-based QES, and has two 10GbE SFP+ ports and redundant power. It's a 2016 model that only takes 2.5-inch drives.
| Bays | 24 |
|---|---|
| CPU | Intel Xeon D-1521; Intel Xeon D-1531; Intel Xeon D-1548 |
| Cores / Threads | 4 / 6 / 8 / - |
| RAM | 16 GB or 32 GB or 64 GB or 128 GB installed (varies by SKU) |
| Product category | - |
| Badge | - |
| Hardware support status | Discontinued |
| OS/app support | Full |
| Technical support end | Active |
| Recommended replacement | - |
| Release year | 2016 |
| RAID levels | JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| PCIe slot types | 1x PCIe Gen 3 x8; 1x PCIe Gen 2 x4 |
| RAM (max) | 64 GB |
| Memory slots | 4 |
| Memory generation | DDR4 |
| Memory speed (MT/s) | 2133 MT/s |
| ECC memory | Non-ECC |
| Memory module type | RDIMM / UDIMM |
| Replaceable memory | Replaceable |
| Network ports | 2x 10GbE |
| USB ports | 2x USB 3.2 Gen 1 |
| PCIe expansion | 4 |
| M.2 slots | None |
| Drive bay types | Front 2.5-inch bays:; 2.5-inch SAS/SATA hard disk drives; 2.5-inch SAS/SATA solid state drives; ; Rear 2.5-inch bays:; 2.5-inch SATA solid state drives / 3.5-inch bays:; 3.5-inch SAS/SATA hard disk drives; 2.5-inch SAS/SATA hard disk drives; 2.5-inch SAS/SATA solid state drives; ; 2.5-inch bays:; 2.5-inch SATA solid state drives |
| Hot-swappable bays | Yes |
| CPU frequency (GHz) | 2.0 / 2.2 / 2.4 |
| Power draw, active (W) | 255.04 |
| Power supply (W) | 47 |
| Dimensions H x W x D | 3.5 x 17.3 x 19.1 in (88 x 439 x 484 mm) |
| Weight | 31.2 lb (14.15 kg) |
Compatible Drives
An exact manufacturer-certified drive list isn't available yet for this model. Based on its bay type, it likely accepts standard 3.5" SATA HDDs such as: Seagate ST16000NM001G, Western Digital WD80EFPX, Western Digital WD8005FFBX, Seagate ST8000VN004, Seagate ST8000NE001, Toshiba HDWG180 — unverified, treat this as a starting point, not a guarantee.
