Status: Legacy / discontinued
An enterprise 3U "double server" from 2019 that combines an app server and a storage server in one box, with dual Xeon E5 v4 chips and up to 1 TB of RAM. You choose between QNAP's ZFS-based QES or the app-heavy QTS system. This is data-center gear, not something for a small office.
| Bays | 20 |
|---|---|
| CPU | Intel Xeon E5-2600 v4 |
| Cores / Threads | 8 / 16 |
| RAM | 64 GB |
| Product category | - |
| Badge | - |
| Hardware support status | Discontinued |
| OS/app support | Full |
| Technical support end | 2026-12-31 |
| Recommended replacement | - |
| Release year | 2019 |
| RAID levels | Single, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| PCIe slot types | 1x PCIe Gen 3 x16; 3x PCIe Gen 3 x8 |
| Memory slots | 16 |
| Memory generation | DDR4 |
| Memory speed (MT/s) | 2133 MT/s |
| ECC memory | Supported |
| Network ports | 4x 10GbE |
| USB ports | 4x USB 3.2 Gen 1 |
| PCIe expansion | 4 |
| M.2 slots | None |
| Drive bay types | 3.5" SAS HDD, 3.5" SAS SSD, 2.5" SAS HDD, 2.5" SAS SSD |
| Hot-swappable bays | Yes |
| CPU frequency (GHz) | 2.1 |
Documents
Compatible Drives
An exact manufacturer-certified drive list isn't available yet for this model. Based on its bay type, it likely accepts standard 3.5" SATA HDDs such as: Seagate ST16000NM001G, Western Digital WD80EFPX, Western Digital WD8005FFBX, Seagate ST8000VN004, Seagate ST8000NE001, Toshiba HDWG180 — unverified, treat this as a starting point, not a guarantee.
