Status: Currently sold
A 4U, 30-bay scale-out storage node built to cluster with other nodes into petabyte-scale storage under QNAP's QuTS MEGA. It runs an 8-core Xeon with 128 GB of ECC memory and has three PCIe Gen 4 slots for 25GbE or M.2 cards. Data protection spreads across nodes rather than traditional RAID, so it's meant for multi-node setups.
| Bays | 30 |
|---|---|
| CPU | Intel Xeon E-2378 |
| Cores / Threads | 8 / 16 |
| RAM | 128 GB |
| Product category | Enterprise Storage |
| Badge | New |
| Hardware support status | Full |
| OS/app support | Full |
| Technical support end | Active |
| Recommended replacement | - |
| Release year | 2025 |
| PCIe slot types | 2x PCIe Gen 4 x4; 1x PCIe Gen 4 x8 |
| RAM (max) | 128 GB |
| Memory slots | 4 |
| Memory generation | DDR4 |
| Memory speed (MT/s) | 3200 MT/s |
| ECC memory | Supported |
| Memory module type | UDIMM |
| Replaceable memory | Replaceable |
| Network ports | 2x 10GbE + 2x 2.5GbE |
| USB ports | 4x USB 3.2 Gen 2 |
| PCIe expansion | 3 |
| M.2 slots | 2 |
| Drive bay types | 3.5-inch bays:; 3.5-inch SATA hard disk drives; 2.5-inch SATA solid state drives; ; 2.5-inch bays: ; 2.5-inch SATA solid state drives |
| Hot-swappable bays | Yes |
| CPU frequency (GHz) | 2.6 |
| Power draw, active (W) | 219.03 |
| Power draw, hibernation (W) | 149.92 |
| Power supply (W) | 800 |
| Dimensions H x W x D | 6.9 x 17.4 x 24.8 in (176 x 442 x 630 mm) |
| Weight | 52.4 lb (23.79 kg) |
- High-capacity Scale-out node
- Intel® Xeon® E-2378 Processor
- 4U 24-bay
Compatible Drives
An exact manufacturer-certified drive list isn't available yet for this model. Based on its bay type, it likely accepts standard 3.5" SATA HDDs such as: Seagate ST16000NM001G, Western Digital WD80EFPX, Western Digital WD8005FFBX, Seagate ST8000VN004, Seagate ST8000NE001, Toshiba HDWG180 — unverified, treat this as a starting point, not a guarantee.
